| Feature | 2BYQF – 4 | 2BYQF – 6 | 2BYQF – 8 |
|---|---|---|---|
| Unit Model | 2BYQF – 4 | 2BYQF – 6 | 2BYQF – 8 |
| Overall Dimensions (mm) | 1750 × 2250 × 1250 | 1830 × 3600 × 1330 | 1650 × 4500 × 1450 |
| Weight (kg) | 530 | 920 | 1090 |
| Row Spacing (mm) | 500, 620 | 500, 620 | 500, 620 |
| Number of Rows | 4 | 6 | 8 |
| Fertilization Depth (mm) | 30-60 (Distance with seeds 60 mm) | 30-60 (Distance with seeds 60 mm) | 30-60 (Distance with seeds 60 mm) |
| Fertilizer Rate (kg/ha) | 0 ~ 140 | 0 ~ 140 | 0 ~ 140 |
| Seeding Depth (mm) | 20 ~ 50 | 20 ~ 50 | 20 ~ 50 |
| Fertilizer Hopper Capacity (L) | 250 | 195 × 2260 × 2 | (Not specified) |
| Seed Hopper Capacity (L) | 18 × 415 × 6 | 18 × 8 | (Not specified) |
| Row Spacing Options (mm) | 80, 100, 120, 130, 140, 150, 160, 170, 180, 200, 230, 250, 280, 300, 330, 360 | 80, 100, 120, 130, 140, 150, 160, 170, 180, 200, 230, 250, 280, 300, 330, 360 | 80, 100, 120, 130, 140, 150, 160, 170, 180, 200, 230, 250, 280, 300, 330, 360 |
| Matched Power (kW / HP) | 33.1 ~ 58.9 (45 ~ 80) | (Not fully specified) | 73.5 ~ 88.2 (100 ~ 120) |
| Rotation Speed (r/min) | 4800 ~ 5500 | (Not specified) | (Not specified) |
| Single Seed Rate (%) | > 92 | > 92 | > 92 |
| Hole Rate (%) | < 3 | < 3 | < 3 |
