Compaction |
|
| Static line load | 125/115 N/cm |
| Nominal amplitude | 0.5-1 mm |
| Vibration frequency | 70 Hz |
| Exciting force | 2×30 kN (dual-wheel vibration) |
| Water tank capacity | 160 L |
|
Engine |
|
| Model | 3B2-35V31 |
| Type | Diesel engine, water-cooled, three-cylinder |
| Power | 26 kW |
| Fuel tank capacity | 108 L |
| Lubricant capacity | 6 L |
| Fuel consumption | 263 g/kWh |
|
Travel |
|
| Speed | 0-15 km/h |
| Turning radius | 2750 mm |
| Climbing ability | 40% |
|
Dimensions/Specifications |
|
| Steel wheel width | 1200 mm |
| Steel wheel diameter | 610 mm |
| Wheelbase | 2127 mm |
| Total length | 3028 mm |
| Total width | 1330 mm |
| Total height | 2500 mm |
| Package dimensions | 3300×1450×2700 mm |
| Operation weight | 2950 kg |
